Paving width   2.5-4.00 m

Auger screw

 Twin Mechanically Drive Abrasion Resistant Auger screw

Paving thickness   Upto 10-200 mm
Paving speed   4-23 m/min


 Twin hydraulic  operated folding hoppers of 4 Cu.m capacity (Approx.)
Travel speed   15 km/h (Max)

Conveyer (Feeder)

 Twin lane type 80 mm pitch, mechanically drive


 Front - Solid rubber type wheel - 2 Nos.
 Rear - 10.00 x 20 - 16 Ply, 2 Nos.

Screed vibrator

  Hydraulic Drive


Screed plates

 450 mm (L) x 2500 mm (W) -   2 Pics
Weight   8500 kegs.(Approx)  450 mm (L) x 150 mm   (W) -   2 Nos
Fuel tank   60 Ltrs  450 mm (L) x 225 mm   (W) -   2 Nos
Hydraulic tanks   45 Ltrs  450 mm (L) x 300 mm   (W) -   2 Nos
1) Power unit  :

The prime over in the Asphalt Paver Finisher  unit is  Kirloskar make model – 4R1040 Diesel engine – 60 HP @ 1800 RPM, with FIP, Air Compressor,  12V alternator, self start starter , 12V – 21 P Excide make battery, radiator, meters like oil pressure, water temperature, ammeter, air meter, hours  meter, starter button, parking key,  dipper switch etc.

2) Hydraulic parts :
  • Hydraulic Cylinder  Dantal make
  • Hydraulic Pump : Dowty make (made in ltaly)
  • Control Valves : Walvoil (made in ltaly)
  • Hydraulic Motors : Dowty make  (made in ltaly)
  • Hydraulic Pipes are Yokohama make. (Korea)
3) Gear system  : Transmission Gear is easy  to maintain in local market.

* Asphalt Cum Wet Mix Paver is available in this model *

Specifications are subject to change without notice due to development
